Frame

The Frame component is useful for cropping content, typically media, to a desired aspect ratio.

Examples

Some examples of where you might use a component:

Installation and Import

First, you must install @bedrock-layout/css.

yarn add @bedrock-layout/css

Then, you can import the entire CSS or just the component's CSS in your project:

import "@bedrock-layout/css/lib/bedrock-layout.min.css";
// or
import "@bedrock-layout/css/lib/components/frame.min.css";

Optionally, you can install the package for your framework of choice (React.js, Solid.js) using your favorite package manager CLI:

## For React.js
yarn add @bedrock-layout/frame
  ## or
yarn add @bedrock-layout/primitives

## For Solid.js
yarn add @bedrock-layout/solid

Then import the component in your project:

// For React.js
import { Frame } from '@bedrock-layout/frame'
  // or
import { Frame } from '@bedrock-layout/primitives'

// For Solid.js
import { Frame } from '@bedrock-layout/solid'

API

computer with data
NameDescriptionDefaultControl
ratio
string
-
children
object
--
as
unknown
"div"
style
unknown
{}
position
-
-

Ratio As String

The ratio prop takes a string the is in the format of ${number}/${number}, which represents the ratio of width to height of the desired aspect ratio. The React and Solid components also accept a string value in the format of ${number}:${number}.

Usage examples

// CSS
<div data-br-frame style={{ "--ratio": "4/3" }}>
  <img src={imgSrc} alt="computer with data" />
</div>

// React.js and Solid.js
<Frame ratio="16/9">
 <Component />
</Frame>

In the example below, the frame will maintain a 16:9 aspect ratio and will crop the image to fit.

computer with data

Ratio As Array

The React and Solid components also accept a ratio prop as an tuple array of two numbers, which represent the ratio of width to height of the desired aspect ratio.

Usage examples

// React.js and Solid.js
<Frame ratio="16/9">
 <Component />
</Frame>

In the example below, the frame will maintain a 4:3 aspect ratio and will crop the image to fit, but the image will be positioned at the top-left of the frame.

computer with data

Without An Aspect Ratio

You can also use the Frame without a ratio. This will allow you to specify the width and height of the frame, while still taking advantage of the cropping functionality.

Usage examples

// CSS
<div data-br-frame style={{ height: "50vh", width: "50%" }}>
  <img src={imgSrc} alt="computer with data" />
</div>

// React.js and Solid.js
<Frame style={{ height: "50vh", width: "50%" }}>
 <Component />
</Frame>

In the example below, the frame's height is set to 50vh and its width is set to 50%. The image will be cropped to fit the frame.

computer with data
